The SmallHD 10 - 2300 - G Bolt 6 XT 12G - SDI/HDMI TX/RX Set with Gold Mount is a game - changer in the world of real - time wireless video transmission. It supports 4K video and uses Teradek’s patented Zero - Delay technology, offering color - accurate, True - HDR videos transmitted in under 0.001 seconds. With the newly opened 6GHz wireless frequency, it has less interference compared to traditional systems. Key features include customizable range options for various production needs, quick reconnection, easy setup via the Bolt Manager App for iOS or Android, and stable connectivity. The 6GHz band not only provides better image quality but also allows for more frequency adjustment options with 12 new channels, especially useful in high - traffic areas. This set can also pass metadata, timecode, and start/stop flags from most camera manufacturers. The Bolt 6 XT has been redesigned to be smaller, lighter, run cooler, and operate 50% quieter than the Bolt 4K. An integrated 5 - pin USB port simplifies wireless camera - control setup when used with SmallHD Smart Monitors. It also offers new tools for high - end users to monitor connections and signals. The included Transmitter and Receiver are cross - compatible with the entire Bolt 4K Series, allowing for workflow expansion. You can link up to 6 receivers to one transmitter or use unlimited receivers in Broadcast Mode (available on MAX models). It offers three line - of - sight range options: 750 ft., 1500 ft., and the MAX Set up to 5,000+ ft. You can also upgrade the set to include Gold or V - Mount Battery plates. The 6GHz frequency provides a quieter wireless environment, though it can still be set up in 5GHz Mode for backwards compatibility. Key features are Zero Delay, 6GHz Wireless Frequency, Bolt 4K Cross - Compatibility, lightweight and quiet operation, built - in 5 - pin USB for camera control, 12G - SDI and HDMI 2.0 inputs and outputs.

Using the SmallHD Bolt 6 XT Set is a breeze. First, connect the transmitter to your camera using the 12G - SDI or HDMI 2.0 input. Make sure to power it on with a suitable power source or optional battery plate. For the receiver, connect it to your monitor or display device using the same output options. Use the Bolt Manager App on your iOS or Android device to set up the system easily. You can choose the range option that suits your production needs, whether it's the 750 ft., 1500 ft., or the MAX Set. When in high - traffic areas, take advantage of the 12 new channels on the 6GHz frequency to reduce interference. Remember, the transmitter and receiver are cross - compatible with the Bolt 4K Series, so you can expand your setup as needed. For camera control, use the integrated 5 - pin USB port when using SmallHD Smart Monitors. As for maintenance, keep the set clean and free from dust. Store it in a cool, dry place when not in use. The operating temperature range is 0 - 40 degrees Celsius, so avoid using it in extreme heat or cold. If you need to upgrade the system, use the USB - C interface. And always ensure the power input is within the specified 6 - 28 VDC range.
